TVS Motor Company
Model Year 2026
TVS Raider Disc
TVS Motor Company TVS Raider Lineup
₹ 91,900
EX-SHOWROOM
Key Highlights & Specifications
Fuel Type
Petrol
Displacement
Air and oil cooled single cylinder, SI
Gearbox
Wet - Multi plate type
Max Power
11.38 PS @ 7500 rpm
Peak Torque
11.2 Nm @ 6000 rpm
Complete Technical Specifications
Engine
| Fuel | Petrol |
| Fuel Capacity | 10 Litres |
| Fuel System | Fuel Injection |
| Engine | Air and oil cooled single cylinder, SI |
| Displacement | 124.8 cc |
| Power | 11.38 PS @ 7500 rpm |
| Torque | 11.2 Nm @ 6000 rpm |
| Number of Cylinders | 1 |
| Number of Valves per Cylinder | 3 |
| Bore | 53.5 mm |
| Stroke | 55.5 mm |
| Transmission | Wet - Multi plate type |
| Gear Box | 5 Speed |
| Drivetrain | Chain Drive |
| Riding Modes | Yes |
| Start Method | Self Start Only |
| Ignition | Electronic Control Unit |
| Acceleration (0 to 100Km/h) | 22.04s |
| Maximum Speed | 99 kmph |
| Cooling System | Air & Oil Cooled |
| Emission | BS6-2.0 |
Body
| Body Type | Sports Bike |
| Length | 2070 mm |
| Width | 785 mm |
| Seat Height | 780 mm |
| Ground Clearance | 180 mm |
| Wheelbase | 1326 mm |
| Tyre Type | Tubeless |
| Tyre Size | Front: 80/100 - 17, Rear: 100/90 - 17 |
| Front Tyre Pressure (Rider only) | 25 psi |
| Rear Tyre Pressure (Rider only) | 28 psi |
| Rear Tyre Pressure (Rider + Passenger) | 32 psi |
| Front Suspension | Telescopic |
| Rear Suspension | Monoshock, 5 step adj, Gas charged |
| Wheel Type | Alloy |
| Wheel Size | Front: 431.8 mm, Rear: 431.8 mm |
| Frame | Single cradle tubular frame |
| Seat Type | Split |
| Passenger Footrest | Yes |
| Storage Under Seat | Yes |
| Additional Storage | Yes |
| Headlight | LED |
| Taillight | LED |
| Indicators | Bulb |
Safety
| Braking System | Synchronized Braking System |
| Front Brake | Disc |
| Front Brake Diameter | 240 mm |
| Rear Brake | Drum |
| Rear Brake Diameter | 130 mm |
Features
| Instrument Console | Digital |
| Speedometer | Digital |
| Odometer | Digital |
| Tripmeter | Digital |
| Clock | Yes |
| USB Charging | Yes |
Battery
| Battery Type | Maintenance Free |
| Low Battery Indicator | Yes |
